Systec

Mediaprep

Mediaprep-10, Mediaprep-20, Mediaprep-30, Mediaprep-45, Mediaprep-65, Mediaprep-90, Mediaprep-120

Brochures

More Info

Specifications

Dimensions and performance

Chamber dimensions Ø x height (mm)

Mediaprep-10
296 × 250

Mediaprep-20
296 × 450

Mediaprep-30
296 × 650

Mediaprep-45
400 × 485

Mediaprep-65
400 × 690

Mediaprep-90
500 × 610

Mediaprep-120
500 × 790

Chamber volume (L)

Mediaprep-10
17

Mediaprep-20
30

Mediaprep-30
44

Mediaprep-45
65

Mediaprep-65
90

Mediaprep-90
126

Mediaprep-120
162

Media vessel dimensions Ø x height (mm)

Mediaprep-10
270 × 222

Mediaprep-20
270 × 422

Mediaprep-30
270 × 622

Mediaprep-45
380 × 452

Mediaprep-65
380 × 657

Mediaprep-90
480 × 572

Mediaprep-120
480 × 752

Media vessel volume (L) total/nomina

Mediaprep-10
12/ 10

Mediaprep-20
23 /20

Mediaprep-30
34/30

Mediaprep-45
51.3/45

Mediaprep-65
74.5/ 65

Mediaprep-90
103.5/ 90

Mediaprep-120
136.1 / 120

Vessel dimensions (mm)

Height

Mediaprep-10
480

Mediaprep-20
715

Mediaprep-30
915

Mediaprep-45
1080

Mediaprep-65
1210

Mediaprep-90
1110

Mediaprep-120
1240

Width

Mediaprep-10
555

Mediaprep-20
555

Mediaprep-30
555

Mediaprep-45
550

Mediaprep-65
550

Mediaprep-90
650

Mediaprep-120
650

Depth

Mediaprep-10
635

Mediaprep-20
635

Mediaprep-30
635

Mediaprep-45
780

Mediaprep-65
780

Mediaprep-90
895

Mediaprep-120
895

Heating power (kW)

Mediaprep-10
3.6

Mediaprep-20
9.3

Mediaprep-30
9.3

Mediaprep-45
20

Mediaprep-65
20

Mediaprep-90
20

Mediaprep-120
20

Mediaprep-10: Voltage 220 - 240 V, 50 / 60 Hz, 16 A.
Mediaprep-20: Voltage 380 - 400 V, 50 / 60 Hz, 16 A.
Mediaprep-30: Voltage 380 - 400 V, 50 / 60 Hz, 16 A.
Other supply voltages available on request
All models: Voltage 380 - 400 V, 50 / 60 Hz, 32 A.
Other supply voltages available on request.
