Daeyong Pharmatech
DWM Series

DWM-1000U, DWM-2000U, DWM-3000U, DWM-4000U, DWT-1000, DWT-2000

Broşürler
Daha Fazla Bilgi

Widely applied to various sizes of ampoule, vial, etc.

Added washing function by ultrasonic generator

Conveyor automatic operation system by sensor

AUTOMATIC UP & DOWN COVER SYSTEM

Exchange of CHANGE PARTS is easy (no special tools required)

Effect of reducing washing water by using circulating water

TOUCH SCREEN HMI SYSTEM for user convenience (PC-based Touch applied)

PIPING LINE : Electrolytic polishing treatment after manufacturing automatic welding with SANITARY PIPE & STS316L material

Diaphragm seal type conforming to GMP regulations (diaphragm type)
(Includes a function to prevent foreign substances and puddles inside the gauge connection pipe)

Turn table type DWT model can be applied excluding ultrasonic washing function depending on the purpose

cGMP and 21 CFR PART 11 applied

CE certification

Proven products with performance of over 100 domestic and overseas units and in normal operation

DESCRIPTION MODEL
DWM-1000U DWM-2000U DWM-3000U DWM-4000U DWT-1000U DWT-2000U
Machine Type Ultrasonic waves Ultrasonic waves Ultrasonic waves Ultrasonic waves Turn Table Type Turn Table Type
Number of Gripper 20 40 60 80 20 40
Number of Nozzle 12 24 24 30 12 24
Machine
Capacity
10㎖ 100 Vial/min 200 Vial/min 300 Vial/min 400 Vial/min 100 Vial/min 200 Vial/min
Main Drive 3P x 220/380V x 0.75kW
Recycling pump 2.2kW
Boost pump 1.5kW
Heater 9.0kW (3kW x 3EA)
Ultrasonic Generator 220V x 600W, 28KHz N/A
Electricity Consumption nstalled Power 3Ø x 220/380V x 16kW
Machine Material Critical Pipe & Nozzle STS316L
Appearance & Body STS304 & Other
Drive Speed Control Inverter Control
Electric Control System PLC for Monitoring
W.F.I consumption (5kg/cm², Ø1.9nozzle inner diameter) 8ℓ/min 10ℓ/min 12ℓ/min 14ℓ/min 8ℓ/min 10ℓ/min
Air consumption
(Ø1.9nozzle inner diameter)
Pressure 3 ~ 5 kg/㎠
Consumption 850ℓ/min 950ℓ/min 1,100ℓ/min 1,300ℓ/min 850ℓ/min 950ℓ/min
Filter Housing Spec. STS316L, 10 inch
Filter W.F.I Filter 0.2 ㎛ PALL (U.S.A)
Circulating water Filter 1.0 ㎛ POLYCLEAN
Air Filter 0.2 ㎛ PALL (U.S.A)
Dimension (L)2,030 X
(W)2,100 X
(H)1,920 mm
(L)2,030 X
(W)2,100 X
(H)1,920 mm
(L)2,030 X
(W)2,100 X
(H)1,920 mm
(L)2,030 X
(W)2,100 X
(H)1,920 mm
(L)2,180 X
(W)2,770 X
(H)1,920 mm
(L)2,180 X
(W)2,770 X
(H)1,920 mm
Weight 2,000kg 2,200kg 2,400kg 2,600kg 2,000kg 2,200kg
