Systec
Mediaprep

Mediaprep-10, Mediaprep-20, Mediaprep-30, Mediaprep-45, Mediaprep-65, Mediaprep-90, Mediaprep-120

Brochures
More Info

Specifications

Dimensions and performance

Chamber dimensions Ø x height (mm)
Mediaprep-10
296 × 250
Mediaprep-20
296 × 450
Mediaprep-30
296 × 650
Mediaprep-45
400 × 485
Mediaprep-65
400 × 690
Mediaprep-90
500 × 610
Mediaprep-120
500 × 790
Chamber volume (L)
Mediaprep-10
17
Mediaprep-20
30
Mediaprep-30
44
Mediaprep-45
65
Mediaprep-65
90
Mediaprep-90
126
Mediaprep-120
162
Media vessel dimensions Ø x height (mm)
Mediaprep-10
270 × 222
Mediaprep-20
270 × 422
Mediaprep-30
270 × 622
Mediaprep-45
380 × 452
Mediaprep-65
380 × 657
Mediaprep-90
480 × 572
Mediaprep-120
480 × 752
Media vessel volume (L) total/nomina
Mediaprep-10
12/ 10
Mediaprep-20
23 /20
Mediaprep-30
34/30
Mediaprep-45
51.3/45
Mediaprep-65
74.5/ 65
Mediaprep-90
103.5/ 90
Mediaprep-120
136.1 / 120
Vessel dimensions (mm)
Height
Mediaprep-10
480
Mediaprep-20
715
Mediaprep-30
915
Mediaprep-45
1080
Mediaprep-65
1210
Mediaprep-90
1110
Mediaprep-120
1240
Width
Mediaprep-10
555
Mediaprep-20
555
Mediaprep-30
555
Mediaprep-45
550
Mediaprep-65
550
Mediaprep-90
650
Mediaprep-120
650
Depth
Mediaprep-10
635
Mediaprep-20
635
Mediaprep-30
635
Mediaprep-45
780
Mediaprep-65
780
Mediaprep-90
895
Mediaprep-120
895
Heating power (kW)
Mediaprep-10
3.6
Mediaprep-20
9.3
Mediaprep-30
9.3
Mediaprep-45
20
Mediaprep-65
20
Mediaprep-90
20
Mediaprep-120
20

Mediaprep-10: Voltage 220 - 240 V, 50 / 60 Hz, 16 A.
Mediaprep-20: Voltage 380 - 400 V, 50 / 60 Hz, 16 A.
Mediaprep-30: Voltage 380 - 400 V, 50 / 60 Hz, 16 A.
Other supply voltages available on request
All models: Voltage 380 - 400 V, 50 / 60 Hz, 32 A.
Other supply voltages available on request.
