Metrological parameters
Maximum capacity [Max]	220 g
Minimum load	10
Readability [d]	0.1 mg
Verification unit [e]	1
Tare range	-220 g
Standard repeatability [5% Max]	0.06 mg
Standard repeatability [Max]	0.07 mg
Standard minimum weight (USP)	120 mg
Standard minimum weight (U=1%, k=2)	12 mg
Permissible repeatability [5% Max]	0.09 mg
Permissible repeatability [Max]	0.1 mg
Linearity	±0.2 mg
Stabilization time	2 s
Adjustment	internal (automatic)
OIML Class	I
Physical parameters
Leveling system	semi-automatic - LevelSENSING
Display	7″ graphic colour touchscreen
Weighing chamber doors	manual
Delivery components	Balance, weighing pan, weighing pan shield, bottom cover, power supply.
Weighing chamber dimensions	190×190×222 mm
Weighing pan dimensions	ø100 mm
Packaging dimensions	490×400×520 mm
Net weight	7.06 kg
Gross weight	9.5 kg
Construction
Protection class	IP 43
Components and software
Database capacity	7
Features of use	Touch-free operation, 2 IR Sensors
Communication interface
Communication interface	RS232¹, 2×USB-A (interchangeable), USB-B, Wi-Fi®, Ethernet
Electrical parameters
Power supply	Adapter: 100 – 240V AC 50/60Hz 0.6A; 12V DC 1.2A
Balance	12 – 15V DC 0.8A max
Power consumption max.	4 W
Environmental conditions
Operating temperature	+10 — +40 °C
Ambient conditions monitoring (option)	THBR 2.0 System, THBR BOX, THB P, THB W, THB S
Relative humidity	40% — 80%
