Metrological parameters
Maximum capacity [Max]	82 / 220 g
Minimum load	1 mg
Readability [d]	0.01 / 0.1 mg
Verification unit [e]	1 mg
Tare range	-220 g
Standard repeatability [5% Max]	0.005 mg
Standard repeatability [Max]	0.06 mg
Standard minimum weight (USP)	10 mg
Standard minimum weight (U=1%, k=2)	1 mg
Permissible repeatability [5% Max]	0.012 mg
Permissible repeatability [Max]	0.08 mg
Linearity	±0.06 / 0.2 mg
Eccentric load deviation	0.2 mg
Sensitivity time drift	1×10⁻⁶/Year×Rt
Stabilization time	4 s
Adjustment	internal (automatic)
OIML Class	I
Physical parameters
Leveling system	automatic - Reflex Level System
Display	10″ graphic colour touchscreen
Weighing chamber	automatic
Weighing chamber doors	automatic
Delivery components	Analytical Balance, weighing pan, weighing pan shield, centring ring, brush, fabric dust cover, power supply.
Weighing chamber dimensions	200×170×220 mm
Weighing pan dimensions	ø90 open-work pan + ø85 (option) mm
Packaging dimensions	750×492×595 mm
Net weight	15.27 kg
Gross weight	19.1 kg
Construction
Protection class	IP 43
Communication interface
Communication interface	2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot
Electrical parameters
Power supply	Adapter: 100 – 240V AC 50/60Hz 1A; 15V DC 2.4A
Balance	12 – 15V DC 1.6A max*
Environmental conditions
Operating temperature	+10 — +40 °C
Operating temperature change rate	±0.3°C/1h (±1°C/8h)
Relative humidity	20% — 80%
Relative humidity change rate	±1%/h (±4%/8h)
